| 安裝環(huán)境Installation environment | 室內樓梯Indoor Stairway |
| 最大行程maximum travel distance | 單次充電100米 Max .100M in single charge |
| 樓梯斜度 Stairway? inclination | 0°-50° |
| 樓梯寬度 Stairway width | 大于700MM(包含休息平臺) More than 700mm(Including the landing platform) |
| 額定載荷 Nominal load | 120KG |
| 額定速度 Nominal speed | 0.1m/s |
| 未折疊尺寸 Unfolded size | 離墻的最大距離680mm Maximum distance to the wall:680mm |
| 折疊尺寸 Folded size | 離墻的最大間距是405mm? Maximum distance to the wall:405mm |
| 軌道距離 Rail size | 離墻的最大間距是155mm? Maximum distance to the wall:155mm |
| 軌道材質 Rail material | 直徑45X3MM無縫鋼管或不銹鋼 Diameter:45X3MM seamless steel pipe or stainless steel |
| 設備電源 Equipment power | 220V,10A,單相，50Hz(僅供充電器使用) 220V,10A,single-phase,50Hz(charger only) |
| 電機功率 Motor power | 200W/24V DC? 2X12VX7AH |
| 控制電壓 Control voltage | 24V/DC |
| 驅動方式Driving mode | 齒輪和齒條 Gear and rack |
| 控制面板 Control panel | 座椅控制手柄及上下遙控器 Seat control handle and up-down remote control |
| 控制方式 Control mode | 點動按住運行 Jogging control,operate by pressing |
| 座椅旋轉 Seat rotation | 0°-90° |
| 設備顏色 Equipment color | 標準色白色（座椅紫紅色） Standard color:white(seat:fuchsia) |
| 安全性能 Safety performance | 旋轉座椅切換開關，安全觸板 Rotary seat switch,safety touch panel |
